Z21 Wall EV Charger, 7kw/11kw/22kw IEC62196 Type 1 charging type,TPU/TPE jacket for lifetime protection, 7kw/9kw/11kw SAEJ1772 Type 1, IP55 Cable, IP54 Station, Card Swipe/APP/Plug&play Start mode, RCD protection:Type B(30mA AC/CCID20+6mA DC)
Waterproof EV charger,Boost your business with the Z21 waterproof EV charger. Designed for durability and efficiency, it ensures safe and reliable charging for your customers every time.
Specification:
| User Interface | Indicator light | |
| Cable routing | Bottom inlet wiring, Bottom outlet wiring | |
| Charging model | Card swipe / APP/Plug&play | |
| Dimension | 265x170x80mm | |
| Input frequency | 50/60Hz | |
| Over-current protection value | ≥110% | |
| Over-voltage protection value | 270Vac for 1 phase; 465Vac for 3 phase | |
| Under-voltage protection value | 190Vac for 1 phase; 330Vac for 3 phase | |
| Over-temperature protection value | 85°C | |
| Electric leakage protection value | 30mA AC+6mA DC | |
| PEN protector | Equipped inside (optional) | |
| Work temperature | -30°C~50°C | |
| Work humidity | -5%~95% non-condensation | |
| Work altitude | < 2000m | |
| Protection Level | IP54 | |
| Cooling Model | Natural cooling | |
| MTBF | 50,000 hours | |
| Sample | Support | |
| Customization | Support | |
| Place of Origin | Zhongshan, Guangdong, China | |
| LED indicator | Blue / Red / Green | |
| RCD | type B (30mA AC + 6mA DC) | |
| Certificate | CE(ICR lab), UKCA, RoHS , ISO ,ETL ,FCC,UL | |
| Warranty | 2 Year(both cable and station) | |
| Control method | Wi-Fi / Blue-booth / App (Optional) | |
| Model No.
And Specification
|
IEC 62196 Type 2 | VCS-Z21-7 1 phase, 32A, AC 250V, 7kW
VCS-Z21-11 3 phase, 16A, AC480V, 11kW VCS-Z21-22 3 phase, 32A, AC480V, 22kW |
| SAAEJ1772 Type1(AC110-240V) | UCS-Z21-32 7KW 32A
UCS-Z21-40 9KW 40A UCS-Z21-48 11KW 48A |
|
